Availability : Usually ships in 15-20 business days
- Great for agriculture, food, and construction worksites.
- Protects children in schools, playgrounds, and festivals.
- Safeguards food for grocery stores, farmers' markets, and outdoor food vendors.
Water Heater Information
This unit is equipped with a heating element to heat the fresh water. It is controlled by a built in thermostat to maintain a nominal water temperature of 110o. The unit is equipped with a float switch to turn off power to the heating element if the water level should drop too low. The unit may take up to one hour to heat the water, depending upon the temperature of the water that it is fi lled with. The system is electrically protected with a GFCI plug. If for some reason, the GFCI were to trip, simply push the reset button on the plug. If the unit trips the GFCI protection again, remove from service, and have a qualified electrician inspect the sink.
All materials, including resin, pigments and additives used to make the plastic components as well as the plumbing components that come in contact with the fresh water supply are U.S. Government Food & Drug Administration (FDA) food grade compliant materials. In certain geographical areas of the USA, a warning decal, "Not for Drinking or Cooking" is required. This sink is supplied with PC-000782 Warning Decal, which is located directly below the faucet. It is suggested that this decal be replaced if it becomes damaged or worn out. All dimensions are subject to change due to environmental factors.
Filling with Fresh Water
NOTE: Unit must be filled prior to plugging in the heater. Unscrew the 1” fill plug located at the top, right hand side of the wash basin. Insert a standard garden or similar type hose and fill with a few gallons of fresh water to perform a system check. Depress the pump a few times to “prime” it (the pump has a built-in check valve that will hold a prime between uses). If needed, continue filling to the top (which is the 17 gallon water level capacity). Tighten the plug when fi nished.
Emptying Fresh Water
Drain the fresh water by unscrewing the 1/2” plug located at the bottom of the sink, to the left of the foot pump. Tighten the plug when finished.
Emptying Gray Water
Wheel the sink to a proper and approved drain location. Pull the hose out from the rib on the back of the holding tank, remove the hose cap and empty the gray water. Replace the cap when finished.
|Water Temperature||Hot Water Only|
|Fresh Water Capacity||17 Gallons|
|Grey Water Capacity||19 Gallons|
|Cabinet Material||Heavy Duty Plastic|
|Sink Height||Adult Height|
|Height||62 in / 157.5 cm|
|Width||18 in / 45.5 cm|
|Depth||22 in / 55.9 cm|
|Pump Capacity (per stroke)||2 fl oz / 59.14 ml|
|Soap Dispenser Capacity||30 fl oz / 887 ml|
|Number of Single Dispenses||1088|
|Paper Towel Capacity||1 Roll or 500 Single Fold (Georgia Pacific 23504)|
|Weight Empty||47 lb / 21.3 kg|
|Weight Full||189 lb / 85.7kg|
|Power Requirement||110V / 15Amp|
|Nominal Water Temp||110 Degrees F|
|Bowl Length||16.0 in|
|Bowl Width||10.0 in|
|Bowl Depth||6.0 in|
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
